Max.drilling capacity

D:12/T:M10/M8

Max.tapping capacity

D:16/T:M12/M10

Diameter of column

70mm

Spindle travel

100mm

Distance from spindle to column

193mm

Max.distance spindle nose to table

315mm

Max.distance spindle nose to base

556mm

Spindler taper

B16/MT2

Spindle speeds range

480~4100r/min

Spindle speeds series

5speeds

Dimension of table surface

200mm x 230mm

Dimension of base

528mmx360mm

Overall height

1037mm

Power of motor

550/750W

G.W/N.W

108kg/90kg

Packing dimension

77cmx42cmx95cm
