Max.drilling capacity

D:20/T:M20/M16

Max.tapping capacity

D:25/T:M24/M20

Diameter of column

85mm

Spindle travel

125mm

Distance from spindle to column

240mm

Max.distance spindle nose to table

297mm/367mm

Max.distance spindle nose to base

560mm/630mm

Spindler taper

MT2/MT3

Spindle speeds range

290~2150r/min

Spindle speeds series

5speeds

Dimension of table surface

280mm x 300mm

Dimension of base

590mmx370mm

Overall height

1127mm

Power of motor

750W/1100W

G.W/N.W

165kg/140kg

Packing dimension

82cmx48cmx102cm
