WhatsApp: +8618266249928WhatsApp: +8618266249928| Model | B6050 | B6063 | |
| Maximum cutting length(mm) | 500 | 630 | |
| Max.range of the horizontal movement of the table | 500 | 630 | |
| Max.distance between the ram bottom and table | 370 | 385 | |
| Max.length of the vertical movement of table | 270 | 360 | |
| Dimensions of table top(L×W) | 440×360 | 630X400 | |
| Max.stroke length of the toolhead | 120 | 120 | |
| Max.swivel angle of the toolhead | ±60° | ±60° | |
| Max.section of tool(W×T)(mm) | 20×30 | 20×30 | |
| Number of ram reciprocation per minute | 14-80 | 14-80 | |
| Range of table feed: | horizontal | 0.2-0.25 0.08-1.00 | 0.4-5.0 |
| Vertical | 0.08-1.00 | ||
| Width of the T-slot for center positioning(mm) | 18 | 18 | |
| Power of the main motor | 3 | 3 | |
| N.W/G.W(kg) | 1650/1760 | 1750/1870 | |
| Overall dimensions(L×W×H)(mm) | 2160×1070×1194 | 2342×1225×1480 | |
Standard accessories with:
Protecting pan, Rubber pad for protecting pan, Triangle belt, Allen wrench, Allen wrench, Crank handle, Spanner, Spanner, Oil gun, Foundation bolts
