WhatsApp: +8618266249928WhatsApp: +86182662499281. The slotting machine is used for slotting planes, forming surfaces and keyways, etc., and can insert work objects such as molds with an inclination within 10°.
2. It is suitable for single or small batch production enterprises.
3. The worktable of the slotting machine has three different directions of feed (longitudinal, horizontal and rotation), so after the work piece is clamped once, several surfaces are processed on this machine.
| Model | Unit | BK5018 |
| Ram maximum slotting length | mm | 180 |
| Ram stroke adjustment | mm | 80 |
| Ram movenent times | N/min | 46/60/90 |
| Work table size | mm | 600X320 |
| Trael of table(X,Y) | mm | 460X320 |
| The knife head suppoting hole axis to column forarm distance | mm | 400 |
| The knife head supporting hole end to Table working distance | mm | 480 |
| X to the motor torque | N.M | 6 |
| Y to the motor torque | N.M | 6 |
| Fast moving | X(m/min) | 5 |
| Y(m/min) | 5 | |
| Ball screw X | FFZD3205-3/P4 | |
| Ball screw Y | FFZD3205-3/P4 | |
| The main motor power | kw | 1.5/2/2.2 |
| Machine weight | kg | 1500 |
Standard configuration:
KND 3 axis CNC controller
Automatic slotting, auto feed and auto retract tools.
X/Y axis are autoamtic positioned, multiple slots can be completed at once in the same plane.
Optional accessories:
GSK, Siemens, FANUC CNC controller
CNC dividing head
CNC rotary table
