WhatsApp: +8618266249928WhatsApp: +86182662499281.750W Copper wire Brushed motor.
2.Mini lathe for hobby DIY and education.
3.Processing materials include wood and metal.
4.OEM service is available.
Model | BV20-1, BV20L-1 |
Distance between centers | 350/520mm |
Swing over bed | 220mm |
Swing over cross slide | 120mm |
Spindle bore | 20mm |
Number of spindle speeds | 6 steps |
Range of spindle speeds | 140-1710rpm |
Range of inch threads | 8-28 I/n” 11 kinds |
Range of metric threads | 0.4-3.0mm 11 kinds |
Top slide travel | 63mm |
Cross slide travel | 115mm |
Tailstock quill travel | 45mm |
Taper of tailstock quill | MT2 |
Motor | 750W Copper wire Brushed motor |
Packing size | 1084/1254*575*600mm |
Net /Gross weight | 110/129 kg, 126/145 kg |
Standard accessories:
3-jaw chuck,
chuck cover,
4-station toolpost,
toolpost cover,
tailstock,
change gears,
oil gun,
wrenches & tool box
Optional accessories:
machine stand,
SINO DRO,
work lamp,
coolant pump,
turning tools,
4-jaw chuck,
live center,
drill chuck,
drill bits
