Distance between centers

700mm

Swing over bed

250mm

Swing over cross slide

140mm

Spindle bore

27mm

Number of spindle speeds

6 steps

Range of spindle speeds

115-1620rpm

Range of inch threads

8-56T.P.T   20 kinds

Range of metric threads

0.2-3.5mm    20 kinds

Top slide travel

65mm

Cross slide travel

115mm

Tailstock quill travel

50mm

Taper of tailstock quill

MT2

Motor

750W Copper wire  Brushed motor

Packing size

1515*575*612mm

Net /Gross weight

162/187 kg
