1.Wide range of pitch for both inch and metric & spindle speed display.
2.All metal gears with high rigidity and long using lift.
3.High rigidity hardened guide way with fine grinding.
4. leadscrew cover with CE and auto-feeding handle.
Model | JY240V |
Distance between centers | 400/550/750mm |
Swing over bed | 250mm |
Swing over cross slide | 150mm |
Spindle bore | 21mm |
Number of spindle speeds | variable speed |
Range of spindle speeds | low 50-1000/high 1000-2000 rpm |
Range of inch threads | 10-44T.P.I |
Range of metric threads | 0.4-3mm |
Top slide travel | 70mm |
Cross slide travel | 115mm |
Tailstock quill travel | 60mm |
Taper of tailstock quill | MT2 |
Motor | 1000W Brushless Motor |
Packing size | 1100/1250/1450*560*570mm |
Net /Gross weight | 135/155/175 kg, 155/180/205 kg |
Standard accessories:
3-jaw chuck,
chuck cover,
4-station toolpost,
toolpost cover,
tailstock,
change gears,
oil gun,
wrenches & tool box
Optional accessories:
machine stand,
SINO DRO,
work lamp,
coolant pump,
turning tools,
4-jaw chuck,
live center,
drill chuck,
drill bits
