CNC Milling Machine
XK7121
INQUIRY
  • Features
  • Specification
  • CONFIGURATION
Specification
XK7121
Table size
660x210mm
T slot (width*qty*space between)
3x14x63 mm x pc x mm
X/Y/Z axis travel
400x220x350mm
Distance between spindle nose and table
45-375mm
Distance between spindle center and column
260mm
Max.speed of the spindle
6000rpm
Positioning accuracy
0.02mm
Repeat posotioning accuracy
0.01mm
Spindle taper
BT30/R8
Main motor power
2.2KW
X/Y/Z feed motor power
2.39/2.39/3.18 NM
Rapid feeding speed X,Y,Z axis
8 m/min
feeding speed
0-2400 mm/min
Min.set unit
0.001 mm
Over dimensions
1450x1240x1890mm
N.W
650kg
