CNC Vertical Milling Machining Center

VMC855

Worktable size 1000x550mm
Travel X/Y/Z axis 850/550/550mm
BT40 spindle with 8000rpm speed
Linear guide way
24 pcs ATC

1. Taiwan or Germany linear guide ways and ball screws.

2. BT40 spindle taper with maximum 8000rpm spindle speed, higher spindle speed 10000/12000rpm is optional.

3. Standard with Taiwan arm type tool magazine with 24 tools for CNC machining.

4. Standard with 3 axis CNC control milling machining center, the 4th axis rotary table with tailstock is optional accessories for your choice.

Item	Unit	VMC855
Table size	mm	1000*550
T slot	No	5
Centre distance	mm	90
T-Width	mm	18
Max. load of worktable	kg	500
Longitudinal travel	mm	800
Cross travel	mm	550
Vertical travel	mm	550
spindle nose to table surface	mm	150-700
Spindle taper		BT40
Speed Range	rpm	40-8000
Spindle output torque (Max.)	N.M	35.8/70
spindle motor power	kw	11/15
cutting feed X/Y/Z	mm / min	1-10000
rapid feed X/Y/Z	m / min	30/30/24
X/Y/Z leadscrew size	mm	40x16
tool magazine capacity	piece	24
tool magazine type		arm type tool magazine
Max. tool weight	kg	8
Max. Tool dia. (full/empty)		78/120
Max. Tool length	mm	300
Tool changing time (tool to tool/cut to cut)	s	1.55/5
Working accuracy
positioning accuracy	mm	±0.005/300 JIS
repeat positioning accuracy	mm	±0.003 JIS
overall dimensions(LxWxH)	mm	255030002800
Machine weight	kg	5500

Standard configuration:

CNC controller GSK,

Taiwan spindle BT40-150-10000RPM (highest speed 8000rpm),

Taiwan or Germany linear guide ways and ball screws,

Taiwan arm type tool magazine with 24 tools,

spindle blowing chip removal system,

spindle air curtain protection

Japan Nachi bearings,

auto centralized lubrication system,

rigid tapping , two water cooling, one air cooling

electrical hand wheel, working lamp, RS232 interface,

alarm light, DNC online processing , schneider electric , heat exchanger

Optional accessories:

the 4th axis rotary table

chain type chip removal system with flushing

Screw type chip removal system with flushing

Renishaw tool setting probe TS27R

BT40-150 direct connection spindle 10000rpm(highest speed 8000rpm)

oil cooler

BT40-150 12000RPM direct connection spindle with oil cooling (highest speed 10000rpm)
