1. High-strength castings, ultra-wide machine base design, single-column structure with high-speed spindle to provide the best structural support and the best cutting rigidity performance.
2. The bed, the column, the sliding seat, the worktable and the headstock have widened ribs and angle support plates, and each joint surface is manually scraped to ensure the rigidity and precision of the overall structure.
3, X, Y, Z three axis adopts Taiwan linear guide pair, 3-axis feed adopts Taiwan's large pitch and high-precision ball screw. The three-axis servo motor and the screw are directly connected. The imported gapless elastic coupling is used. The transmission has no gap, the moment of inertia is small, and the transmission rigidity is high.
4. The spindle adopts 6000 rpm high-speed, high-precision spindle unit, equipped with NSK bearings imported from Japan and automatic tooling device. The main shaft adopts a central air blowing structure. Before the tool change, the inner cone hole and the tool shank are cleaned to remove the residue and ensure the high precision and rigidity of the spindle.
5. The machine is cooled by a flow cooling pump, high pressure swarf and fully cooled.
6. The electric pump centralized automatic lubrication device
7. The X, Y and Z three-axis guide screws are sealed to ensure the cleaning of the lead screw and the guide rail to ensure the transmission and movement precision of the machine tool. The external protection of the machine tool is designed with a fully enclosed structure, which is safe and reliable.
9, CNC system control system features complete, easy to operate, standard RS-232 communication interface and related software, with DNC online processing capabilities.
10. The tool magazine adopts Taiwan famous brand bucket magazine. The magazine has a capacity of 12 knives.
